Description

TP-Link CPE605 Outdoor CPE for Focused Long-Range 5GHz Wireless Links

The TP-Link CPE605 combines a high-gain 23dBi directional antenna with a 5GHz 802.11a/n radio to create focused outdoor wireless links where running network cable between locations is impractical.

Its directional design is intended for accurately aligned links rather than general wide-area Wi-Fi coverage, making it suitable for point-to-point connections between buildings and compatible point-to-multipoint Pharos networks.

Is This Right for You?

• Suitable for linking two network locations wirelessly across an outdoor line-of-sight path.
• A good choice where a highly directional 23dBi antenna is preferred over broad omnidirectional coverage.
• Suitable for compatible Pharos point-to-point and point-to-multipoint deployments.
• Consider a faster model if your link requires more than the CPE605’s maximum 150Mbps wireless PHY rate or faster than 100Mbps wired Ethernet.

How It Works

The directional antenna concentrates radio energy into a narrow beam. For a point-to-point link, compatible outdoor wireless units are installed with suitable line of sight and accurately aligned towards each other. The CPE605 is powered through its Ethernet cable using passive PoE, reducing the need for a separate power outlet at the outdoor mounting position.

Why Choose This Product?

• Focused long-range signal: The 23dBi directional Cassegrain antenna and dedicated reflector provide narrow beam directivity for outdoor wireless links.
• Designed for outdoor installation: An IP65 enclosure helps protect the unit from dust and water exposure in suitable installations.
• Improved multi-device efficiency: Pharos MAXtream TDMA technology is designed to improve throughput, capacity and latency in compatible deployments.
• Flexible mounting: Snap-lock assembly, pole mounting hardware and three-axis alignment help installers position the antenna accurately.
• Centralised management: Pharos Control supports device discovery, monitoring, firmware management and network maintenance from a PC.

Before You Buy

• The CPE605 operates on the 5GHz band and supports IEEE 802.11a/n; it is not a dual-band Wi-Fi access point.
• Its single wired network interface is 10/100Mbps Ethernet, so it does not provide a Gigabit Ethernet connection.
• Power is supplied through passive PoE over the Ethernet connection. The supported input range is 16–27V DC, and a 24V 0.25A passive PoE adapter is included.
• Long-distance performance depends on alignment, permitted transmit power, interference, obstacles and environmental conditions. TP-Link’s stated distance is not a guaranteed installation range.
• Proper grounding and shielded cabling are important for the specified ESD and lightning-protection measures.

Technical Specifications

What’s in the Box

• 1 × TP-Link CPE605 Outdoor Wireless CPE
• 1 × 24V 0.25A Passive PoE Adapter
• Pole Mounting Kits
• AC Power Cord
• Installation Guide
