Name: Tiandy TC-R3220P 20-Channel NVR | 16 PoE Ports
Brand: Tiandy
SKU: TC-R3220-P
Availability: InStock

Sale!

Tiandy TC-R3220P 20-Channel NVR | 16 PoE Ports

Original price was: R7,970.00.Current price is: R4,371.00. Incl. VAT

20-channel IP NVR
16 × built-in PoE ports
Up to 8MP recording resolution
Dual SATA HDD support
4K HDMI + VGA output
S+265/H.265/H.264 compression
N+M redundancy and ANR
1 × RJ-45 LAN port (10/100/1000 Mbps)
Alarm I/O 4 in / 1 out
Aluminium housing
Includes IR remote, mouse and power adapter

SKU: TC-R3220-P Categories: CCTV & Surveillance, NVRs, Video Recorders Brand: Tiandy

Description

Tiandy TC-R3220P 20-Channel NVR with 16 PoE Ports

The Tiandy TC-R3220P is a professional-grade 20-channel PoE NVR designed for medium to large surveillance systems. With 16 built-in PoE ports, this recorder powers and connects multiple IP cameras directly, reducing infrastructure requirements and simplifying installation. Featuring 4K HDMI output, dual SATA bays and advanced video compression, it delivers reliable performance and long-term storage for demanding security environments.

Key Features

20-channel IP camera support for scalable systems
16 × built-in PoE ports for direct camera powering and network connection
Supports recording resolutions up to 8MP
Dual SATA HDD bays for high-capacity storage
Advanced S+265 / H.265 / H.264 compression to maximise recording efficiency
4K HDMI and VGA display output
N+M redundancy and ANR (Automatic Network Replenishment) support
Smart playback and search tools
Remote viewing via mobile app or web browser
ONVIF support for wide camera compatibility
Durable aluminium housing for improved heat management

Applications

Commercial CCTV installations
Retail and office premises
Residential estates and complexes
Warehouses, logistics and industrial environments
Multi-camera surveillance with local PoE power distribution

Technical Specifications

Specification	Details
Channels	20 IP video channels
PoE Ports	16 × PoE ports (RJ-45)
LAN Port	1 × RJ-45 LAN port (10/100/1000 Mbps self-adaptive)
Max Resolution	Up to 8MP recording
Display Output	HDMI up to 4K, VGA
Storage	2 × SATA HDD bays (high-capacity support)
Compression	S+265 / H.265 / H.264
Redundancy	N+M support
ANR	Supported
Alarm I/O	4 in / 1 out
USB Ports	2 × USB
Control	IR remote + USB mouse
Housing	Aluminium chassis

Why Choose the TC-R3220P

With powerful PoE capability and advanced recording architecture, the TC-R3220P supports high-resolution deployment, efficient storage and stable large-scale CCTV operation. Ideal for professional installations requiring central PoE power and reliable 24/7 recording.

What’s in the Box

1 × Tiandy TC-R3220P NVR
USB mouse
IR remote
Power adapter
Mounting screws and accessories
User guide

Surveillance Hard Drives Sold Separately

Storage Guide – Quick Reference

Typical CCTV system recommendations:

Up to 4 cameras → 1TB – 2TB
4–8 cameras → 2TB – 4TB
8–16 cameras → 6TB – 10TB
4K cameras or longer retention → Higher capacity recommended

Consider more storage if recording 24/7 or in 4K.

Calculate Your Exact Storage Needs

Use the WD capacity calculator to determine the perfect drive size for your system.

WD Surveillance Storage Calculator (opens external Link)

Additional information

Weight	3050 g
Dimensions	47.5 × 277 × 440 mm
DVR / NVR Channels	20 Channel
NVR Built-in PoE Ports	16

Tiandy TC-R3220P 20-Channel 16 PoE Port NVR Data Sheet
