Description

Hikvision DS-2CE72KF3TP-DLS 2.8mm ColorVu 180° Dual-Lens Turret Camera for Wide-Area CCTV

The Hikvision DS-2CE72KF3TP-DLS is designed for areas where a conventional camera cannot comfortably cover the full scene. Two 2.8mm lenses capture adjacent views and Hikvision’s built-in stitching algorithm combines them into one 180° panoramic image.

This makes it particularly useful across wide entrances, building fronts, parking areas, yards and other open spaces. ColorVu low-light imaging, Smart Hybrid Light, true WDR and a built-in microphone add strong day-and-night performance without requiring multiple separate camera views.

Is This Right for You?

• Choose this camera when you need an exceptionally wide view from a single HD analogue camera position.
• It is particularly useful for wide entrances, yards, parking areas, shopfronts, warehouses and building perimeters.
• The fixed 180° panoramic view prioritises broad situational awareness rather than a narrow view of a distant target.
• If you need optical zoom or an adjustable viewing angle, choose a varifocal camera instead.
• This model requires compatible HD analogue recording equipment capable of supporting its panoramic 3K output.

How It Works

The camera uses two fixed 2.8mm lenses to capture adjacent parts of the scene. A built-in stitching algorithm combines these feeds into one continuous 180° horizontal panoramic image, allowing a single camera position to monitor a much wider area than a conventional fixed-lens camera.

Why Choose This Product?

• 180° coverage from one camera: The dual-lens design can reduce blind areas across wide spaces and may reduce the number of separate camera viewpoints required.
• Detailed panoramic footage: The camera outputs 3328 × 1504 video at 20fps, providing approximately 5MP of image information across the panoramic scene.
• Strong low-light colour performance: ColorVu imaging combines an F1.0 aperture with a minimum illumination rating of 0.0005 lux with AGC enabled.
• Flexible night lighting: Smart Hybrid Light provides infrared and visible white-light illumination, with both rated for distances of up to 40m.
• Clearer difficult scenes: At least 130dB true WDR helps balance areas containing strong backlighting, such as entrances facing bright daylight.
• Audio built in: The integrated microphone allows compatible recording equipment to capture sound together with the video over the coaxial connection.
• Suitable for exposed locations: IP67 protection provides dust and water resistance for indoor or outdoor surveillance installations.

Before You Buy

• This is an HD analogue panoramic camera and requires a compatible DVR. It does not connect directly to an NVR, Ethernet network or PoE switch.
• The camera uses dual fixed 2.8mm lenses and provides a stitched 180° horizontal and 75° vertical field of view.
• South African supplier documentation recommends compatible Hikvision /XT DVR models for this camera’s panoramic output; confirm DVR compatibility before ordering for an existing system.
• The current specification uses 12V DC ±25% power with maximum consumption of 8.9W. A 15V DC adapter is required where the specified high-impedance cabling condition applies.
• Audio is provided by the built-in microphone over the coaxial connection, so the connected DVR must support the required audio functionality.
• No onboard MicroSD storage interface is specified for this model; recording should be provided by the compatible DVR.

Technical Specifications

What’s in the Box

• 1 × Hikvision DS-2CE72KF3TP-DLS 2.8mm Dual-Lens Turret Camera
