Centurion D6 Smart Sliding Gate Motor

R5,999.00R6,134.00 Incl. VAT

Ideal for light industrial sites for gates weighing up to 600kg

  • Onboard multichannel NOVA receiver with 1500 button memory
  • Wireless setup and configuration via smartphone
  • 24V system for extended operations and battery backup
  • Vibration sensor for tamper notifications via third-party devices
  • Intelligent battery charger with onboard diagnostics and SMART communication
  • Enhanced position control with hall effect technology
  • Individually-configurable inputs and outputs
  • Single-action manual release for convenience
  • Improved theft-resistant cage with patented design (not included)

*Price includes the Motor and 2x 4 Button NOVA Remotes only! Excludes foundation plate, batteries, rack and accessories.

NOTE: Foundation / Base plate not required if replacing existing D3 / D5 gate motor.



Original price was: R6,925.00.Current price is: R5,999.00. Incl. VAT
Original price was: R7,121.00.Current price is: R6,134.00. Incl. VAT
SKU: N/A Category: Brand:

Description

Centurion D6 Smart Sliding Gate Motor – Gates up to 600kg.

All the most innovative technological features

  • Onboard multichannel NOVA receiver with 1500 button memory
  • Wireless and effortless – easy setup and configuration from your smartphone
  • 24V system capable of performing more operations and offering extended battery backup and power failure autonomy
  • Vibration sensor that can be connected to a third party device to notify you in the event that the gate motor is being tampered with
  • Intelligent battery charger with onboard diagnostics and SMART communication between the charger and the controller
  • Improved position control system incorporating hall effect technology – highly resistant to interference
  • Individually-configurable inputs and outputs
  • Convenient and intuitive single-action manual release
  • New and improved theft-resistant cage with a patented design offering outstanding security and peace of mind (not included)



Technical Specifications

D6-SMART
Input voltage (1)90V – 240V AC +/-10% @ 50Hz
Current consumption (Mains)200mA
Battery charger current output1.3A
Maximum number of operations per day150
Duty cycle – Mains present (2, 3)50%
Motor voltage24V DC
Motor power supply (5)Battery-driven (Standard Capacity – 2x12V)
Current consumption (motor at rated load)13A
Input / Output sink currents (Max accessory current draw)
I/O 1-4100mA (12/24V)
I/O 5 and 63A (12/24V) 10sec Pulse
Motor push force – starting30kgf
Motor push force – rated17kgf
Gate mass – maximum600Kg
Gate length – maximum100m
Gate speed (varies with load) (4)35m/min @ 17kgf
Manual OverrideLockable with key release
Operations in standby with 2 x 7Ah (28W) battery
Half day (5, 6)209 (Power Saving)/ 102 (Normal)
Full day (5, 6)183 (Power Saving)/ 79 (Normal)
Collision SensingElectronic
Operating temperature range-15°C to +50°C
On-board receiver typeCode-hopping multichannel receiver with selective add and delete
Receiver code storage capacity (7)1500 Remotes
Receiver frequency433.92MHz
Degree of protectionIP55
Mass of unit packed (with standard kit, but excl. rack and battery)9.1kg
Packaging dimensions (with standard kit, but excl. rack and battery)325mm wide x 244mm deep x 445mm high
  1. Can operate off a solar supply, consult your local dealer for assistance
  2. Based on 25°C ambient temperature and unit not in direct sunlight
  3. Based on a motor push force of less than 50% of rated (Starting and Running forces)
  4. Gate opening and closing speeds can be configured to run slower depending on the requirements of individual installations
  5. Can increase battery capacity for longer standby times
  6. Based on 4m gate, excluding all accessories
  7. Multiple buttons per remote can be used



What’s in the Box:

  • 1x Centurion D6 Smart Sliding Gate Motor
  • 2x 4 Button NOVA Remotes

*Excludes Batteries (x2), Rack, Foundation Plate and Accessories

D6-SMART Sliding Gate Motor Brochure (1MB)

D6-SMART Installation Guide (5.68MB)



Additional information

Weight9100 g
Dimensions325 × 244 × 445 mm
D6 Motor

Excluding Base Plate, Including Base Plate
