Sale!
TP-Link Gigabit Multi-Mode Fibre Media Converter with SC and RJ45 – MC200CM
TP-Link Gigabit Multi-Mode Fibre Media Converter with SC and RJ45 | MC200CM - Image 2
TP-Link Gigabit Multi-Mode Fibre Media Converter with SC and RJ45 | MC200CM - Image 3
TP-Link Gigabit Multi-Mode Fibre Media Converter with SC and RJ45 | MC200CM - Image 4
TP-Link Gigabit Multi-Mode Fibre Media Converter with SC and RJ45 | MC200CM - Image 5
TP-Link Gigabit Multi-Mode Fibre Media Converter with SC and RJ45 | MC200CM - Image 6
TP-Link Gigabit Multi-Mode Fibre Media Converter with SC and RJ45 – MC200CM

TP-Link Gigabit Multi-Mode Fibre Media Converter with SC and RJ45 | MC200CM

Original price was: R599.00.Current price is: R539.00. Incl. VAT

  • Converts 1000BASE-SX multi-mode fibre to Gigabit Ethernet copper connections and vice versa
  • Includes one 1000Mbps SC/UPC fibre port and one 10/100/1000Mbps RJ45 port
  • Supports multi-mode fibre links up to 550 metres using 50/125µm fibre
  • Operates at an 850nm optical wavelength for Gigabit shortwave fibre connections
  • Auto-negotiating RJ45 port supports Auto-MDI/MDIX for straightforward network integration
  • Can operate as a standalone converter or be installed in a compatible TP-Link TL-MC1400 chassis
  • Front-panel LED indicators simplify power and connection-status monitoring
SKU: MI-TP-MC200CM Categories: , , Brand:

Description

TP-Link MC200CM Gigabit Multi-Mode Media Converter for SC Fibre Links

The TP-Link MC200CM provides a straightforward way to bridge a Gigabit copper Ethernet connection and a 1000BASE-SX multi-mode fibre link. It is useful where an Ethernet network needs to extend beyond the normal 100m copper-cable limit.

Its SC/UPC fibre interface operates at 850nm and supports multi-mode fibre distances of up to 550m with 50/125µm fibre, while the Gigabit RJ45 connection automatically handles MDI/MDIX.

Is This Right for You?

  • Choose the MC200CM when your fibre link uses 1000BASE-SX multi-mode fibre and SC connectors.
  • It suits network extensions between buildings, cabinets or equipment locations where copper Ethernet alone cannot cover the required distance.
  • For single-mode fibre or substantially longer fibre runs, use a converter designed for the appropriate single-mode standard instead.

Why Choose This Product?

  • Extend Gigabit Ethernet over fibre: The converter bridges 1000BASE-T copper Ethernet and 1000BASE-SX fibre without replacing compatible network equipment at each end.
  • Up to 550m on suitable fibre: 50/125µm multi-mode fibre supports links up to 550m, giving considerably more reach than a standard copper Ethernet segment.
  • Simple SC connectivity: The dedicated 1000Mbps SC/UPC interface is designed for common multi-mode fibre installations rather than requiring a separate SFP module.
  • Flexible deployment: The MC200CM can operate as a standalone unit or be installed in a compatible TP-Link TL-MC1400 media-converter chassis.
  • Easy status checking: Front-panel power and link/activity indicators help confirm the converter and network link are operating.

Before You Buy

  • The fibre connection must use compatible 1000BASE-SX multi-mode fibre with an SC-type connection.
  • Maximum fibre distance is 550m with 50/125µm fibre and 220m with 62.5/125µm fibre.
  • The RJ45 side supports Category 5 or Category 5e UTP cable up to 100m, or compatible EIA/TIA-568 100Ω STP.
  • The converter uses an external power adapter and has a maximum power consumption of 1.66W.
  • A TP-Link TL-MC1400 chassis is optional and is not required for standalone operation.

Technical Specifications

ModelMC200CM
Product TypeGigabit multi-mode fibre media converter
Fibre Interface1 × 1000Mbps SC/UPC port
Ethernet Interface1 × 10/100/1000Mbps RJ45 port with Auto-MDI/MDIX
Fibre Standard1000BASE-SX multi-mode fibre
Ethernet Standard1000BASE-T
Wavelength850nm
Transmission Distance – 50/125µm FibreUp to 550m
Transmission Distance – 62.5/125µm FibreUp to 220m
Ethernet Cable DistanceUp to 100m
StandardsIEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Transfer ModeHalf-duplex / full-duplex auto-negotiation
LED IndicatorsPower, Link/Activity
Power SupplyExternal power adapter
Power Requirement9V DC / 0.6A
Maximum Power Consumption1.66W
Dimensions (Length × Width × Height)73 × 94.5 × 27mm
Operating Temperature0°C to 40°C
Operating Humidity10% to 90% non-condensing

What’s in the Box

  • 1 × TP-Link MC200CM Media Converter
  • 1 × Power Adapter
  • 1 × Installation Guide

Additional information

Dimensions95 × 73 × 27 mm
