Sherlotronics S4 4 Channel Transmitter 12v

R515.00 Incl. VAT

Sherlotronics S4 – 12V 4 Channel Stand-Alone Transmitter – 1.5km Range Code-Hopping – 403MHz

Can be used for transmission of alarm signals, linking electric fence outputs to alarms, switching  pumps on and off on farms, industrial machinery control, wireless control of generators and more.

Description

Sherlotronics S4 12v Stand-Alone 4 Channel Transmitter – 403MHz

Applications

  • Transmission of Alarm signals
  • Linking Electric Fence outputs to Alarms
  • Switching On / Off Pumps on farms
  • Industrial Machinery Control
  • Wireless control of Generators



Features

  • Code-Hopping Encryption
  • 1500m Long Range
  • 4-Channel telemetry outputs
  • Normally open or Normally closed trigger inputs
  • LED indication when a channel is triggered
  • 1 or 3 transmit signals can be selected
  • All inputs are supervised
  • On/Off software functionality



Specifications

  • Encryption: Code-Hopping
  • Range: 1500m (Open air)
  • Frequencies: 403MHz / 433MHz
  • Voltage Range: 9.8V to 16V DC
  • Current on TX: >90mA
  • Sleep mode: >10mA
  • Dimensions (L x W x H): 187 x 104 x 67mm
  • Gross Weight: 235 grams
  • Operating Temp: -3°C to 65°C
  • Warranty: 24 Months

S4 Installation Manual



Additional information

Weight237 g
Dimensions185 × 104 × 67 mm
