Sherlotronics S1 1 Channel Transmitter 12v

R253.00 Incl. VAT

Sherlotronics S1 – 12V 1 Channel Transmitter – 150m Range Code-Hopping – 403MHz

Can be used for transmission of alarm signals, linking electric fence outputs to alarms, switching  pumps on and off on farms, industrial machinery control, wireless control of generators and more.

Description

Sherlotronics S1 12v Stand-Alone 1 Channel Transmitter – 403MHz

Applications

  • Transmission of Alarm signals
  • Linking Electric Fence outputs to Alarms
  • Switching On / Off Pumps on farms
  • Industrial Machinery Control
  • Wireless control of Generators



Features

  • Code-Hopping Encryption
  • 1-Channel outputs
  • 12V DC – Positive / Negative trigger
  • Normally open or Normally closed inputs
  • LED indication when the unit is triggered



Specifications

  • Encryption: Code-Hopping
  • Range: 500m (Open air)
  • Frequencies: 403MHz / 433MHz
  • Voltage Range: 9.8V to 16V DC
  • Current on TX: +/-30mA
  • Sleep mode: +/-9mA
  • Dimensions: (L x W x H) 187 x 104 x 67mm
  • Gross Weight: 50 grams
  • Operating Temp: -3°C to 65°C
  • Warranty: 24 Months

S1 Installation Manual

S1 V2.3 Instruction Manual Rev2021



Additional information

Weight135 g
Dimensions100 × 60 × 25 mm
