Description

EZVIZ T9C Indoor / Outdoor Smart Siren

The EZVIZ T9C Smart Siren adds a loud on-site alert to your EZVIZ smart home setup, helping you respond faster when unusual activity is detected. Built for both indoor and outdoor use, it combines a weatherproof housing with flexible sound and timing settings, making it suitable for entrances, patios, passageways, garages and other protected areas around the home.

Key Features

Adjustable alarm sound and duration

The T9C allows you to set the siren output between 90 dB and 105 dB, with an alarm duration adjustable from 5 seconds to 180 seconds. This gives you better control over how the siren behaves depending on where it is installed and how you want alerts handled.

Suitable for indoor and outdoor use

With its IP54 weatherproof design, the T9C can be installed in a variety of sheltered outdoor or indoor locations, giving you more flexibility than a standard indoor-only siren.

Tamper and movement protection

The siren supports both a tamper alarm and an anti-moving alarm. If someone interferes with the unit or attempts to move it from its mounted position, the system can trigger an alert to help protect the device and improve overall system awareness.

Smart integration with the EZVIZ system

The T9C is designed to work as part of the EZVIZ smart home range. It can be linked to compatible EZVIZ sensors and, through the EZVIZ app, allows users to manage alerts, notifications, arming and disarming functions more conveniently. A compatible EZVIZ gateway is required for operation.

Long battery life with power flexibility

The siren can operate on 4 × CR123A batteries and also supports 12V DC external power. In standby mode without alarm activity, EZVIZ states battery life can reach up to 8 years, depending on the configured sound level, alarm duration and frequency of use.

Technical Specifications

• Model: CS-T9C-A0-BG
• Alarm sound level: 90 to 105 dB adjustable
• Alarm duration: 5 to 180 seconds adjustable
• Functions: Low battery reminder, tamper alarm, moving alarm
• Installation method: Wall mounted
• Protocol: ZigBee 3.0
• Wireless frequency: 2.4 GHz
• Communication distance: Less than 200 m in open environment
• Power supply: 4 × CR123A batteries or 12V DC external power
• Standby current: ≤ 60 μA (battery), ≤ 1 mA (DC12V)
• Alarm current: ≤ 1.2 A (battery), ≤ 0.5 A (DC12V)
• Operating conditions: -30 °C to 60 °C, ≤ 95% RH non-condensing
• Storage temperature: -20 °C to 60 °C
• IP rating: IP54
• Dimensions: 134 × 51.5 mm
• Weight: 437.54 g

Applications

• Smart home intrusion alert systems
• Indoor or sheltered outdoor warning siren applications
• Pairing with EZVIZ door, motion, smoke or environmental sensors
• Homes, flats, garages, outbuildings and small offices using the EZVIZ ecosystem

Additional Information

The EZVIZ T9C is not a standalone siren and requires a compatible EZVIZ gateway / hub to function within the EZVIZ smart home system. It is best suited to users already building or expanding an EZVIZ sensor-based security setup.

What’s in the Box

• EZVIZ T9C Smart Siren
• Mounting accessories
• Quick start documentation
