Centurion Photon II Wireless Safety Beams (Part Wireless)

Original price was: R972.00.Current price is: R799.00. Incl. VAT

hoton II infrared gate safety beams with wireless technology are designed to prevent the gate from closing onto vehicles and obstructions. The Transmitter wirelessly pairs to the Receiver however the Receiver must be wired to the gate motor.

  • Transmitter Power Supply: 2x AA Alkaline batteries (supplied)
  • Receiver:  12-24vAC | 12-30vDC
  • Transmitter Battery Life: Minimum 2 years
  • Battery Low Indication: Audible beep
  • Specified Operating Distance: 30m
  • Alignment: Automatic 1m² @ 10m (circular area)
  • Degree of Protection: IP54



SKU: PHOTON1V2 Category: Brand:

Description

Centurion Photon II Wireless Safety Beams (Part Wireless)

Safety has never been so quick and easy – thanks to wireless technology! Introducing CENTURION’s Photon II infrared gate safety beam with a wireless transmitter. Photon II makes short work of achieving a safe automation system for even the most challenging of installations. With a wireless transmitter there’s no need to tunnel under the driveway. Simply align, attach and you’re away!



Main Features

  • The transmitter is wireless and battery-operated saving time and money.
  • Two-year battery life using two AA Alkaline batteries (included).
  • Thirty-metre operating range – ideal for almost any entrance gate.
  • Fully ant-proof and weather-resistant enclosure for greater reliability.
  • Transmitter provides audible feedback for easy setup and battery-low indication.
  • Low power consumption throughout the system for greater efficiency.
  • Installer Mode with audible feedback makes alignment a dream.
  • Elegant slimline construction – only 50mm wide.
  • Compatible with Intruder-detection Alarms for enhanced perimeter security.



Technical Specifications

Power Supply Transmitter2x AA Alkaline Batteries (Supplied) Only replace with alkaline batteries; do not use rechargeable batteries with this product
Receiver12 – 24V AC 12 – 30V DC
Receiver Power Consumption30mA @ 12V DC
Transmitter Battery LifeMinimum 2 years
Battery Low IndicationAudible Beep
Specified Operating Distance30m
AlignmentAutomatic – 1m² @ 10m (circular area – assumes parallel surface)
Output ContactFail-safe, N/C and N/O, potential free contact
Output Contact Rating3A @ 30V DC Non-inductive
Operating Temperature-15°C – +65°C
Operating Humidity0 – 90° Non-condensing
Housing Material0 – 90° Non-condensing
Degree of ProtectionIP54



Centurion Photon II Wireless Safety Beams Manual



Additional information

Weight200 g
